Name
|
WTH
|
|
Dimension
|
110mm(L)×80mm(W)×33mm(H)
|
|
Housing
|
ABS
|
|
Weight
|
300g (w/o Battery, Antenna)
|
|
Power Supply
|
AA size 3.6Volt LITHIUM BATTERY 1EA or 2EA
|
|
Current Consumption
|
Tx 190mA, Rx 140mA (@3.6Vdc)
|
|
Operating Temperature
-
|
-40℃ ~ +85℃
|
|
RF Features
|
ㆍFrequency : 2412 ~ 2472 MHz
ㆍStandard Supported : IEEE 802.11b
ㆍTransmitter Power : Max. 7mW
ㆍModulation
IEEE 802.11b : DSSS : 1Mb/s and 2Mb/s
IEEE 802.11b : CCK : 5.5Mb/s and 11Mb/s
ㆍChannels
Europe - 13 channels
USA - 11 channels
|
|
Performance
|
ㆍRF Data Rate: 1Mb/s to 11Mbps
|
|
I/O Interface
|
ㆍUSB Connector
|
|
Antenna Interface
|
ㆍSMA(Female, Reverse)
ㆍImpedance 50Ω
|
|
Sensor
|
Temperature
/Humidity
|
ㆍAccuracy
Humidity : ±3.0 Temperature : ±0.4 @℃ |
