Name
|
UTH
|
|
Dimension
|
110mm(L)×80mm(W)×33mm(H)
|
|
Housing
|
ABS
|
|
Weight
|
300g (w/o Battery, Antenna)
|
|
Power Supply
|
AA size 3.6Volt LITHIUM BATTERY 1EA or 2EA
|
|
Current Consumption
|
Tx 190mA, Rx 20mA (@3.6Vdc)
|
|
Operation Temperature
|
-20℃ ~ +50℃
|
|
RF Features
|
ㆍFrequency : 433.050MHz ~ 434.790MHz
ㆍChannel Spacing : 25KHz
ㆍTransmitter Power : 10mW
ㆍReceiver Sensitivity : -116 ~ -120dBm(-116dBm typ.)
ㆍModulation : FSK
ㆍBandwidth : < 14KHz
|
|
RF Performance
|
ㆍExpected Line-Of-Sight Range : Up To 1.5km with λ/4 Dipole Antenna
ㆍRF Data Rate : 4.8K Baud, 7.2K Baud
|
|
I/O Interface
|
ㆍUSB Connector
|
|
Antenna Interface
|
ㆍSMA(Female)
ㆍImpedance 50Ω
|
|
Sensor
|
Temperature
/Humidity
|
ㆍSHT15(SENSIRION)
ㆍAccuracy
Humidity : ±2.0 Temperature : ±0.3 @℃ |
